| 규격/기호 | A1 | A2 | L | L1 | 공차 |
| 13 ×13 | 42 | 20 | 40 | 17 | ±3 |
| 20 ×13 | 45 | 23 | 48 | 22 | ±3 |
| 20 × 20 | 48 | 23 | 48 | 22 | ±3 |
| 25 × 13 | 50 | 28 | 53 | 22 | ±3 |
| 25 × 20 | 53 | 28 | 53 | 27 | ±3 |
| 25 × 25 | 53 | 28 | 53 | 27 | ±3 |
| 30 × 13 | 61 | 40 | 66 | 30 | ±5 |
| 30 × 20 | 57 | 33 | 66 | 30 | ±5 |
| 30 × 25 | 57 | 33 | 66 | 30 | ±5 |
| 30 × 30 | 68 | 34 | 66 | 30 | ±5 |
| 40 × 13 | 68 | 46 | 73 | 36 | ±3 |
| 40 × 20 | 64 | 40 | 73 | 36 | ±3 |
| 40 × 25 | 64 | 40 | 73 | 36 | ±3 |
| 40 × 30 | 74 | 40 | 73 | 36 | ±3 |
| 40 × 40 | 76 | 40 | 73 | 36 | ±3 |
| 50 × 13 | 71 | 49 | 69 | 24 | ±3 |
| 50 × 20 | 67 | 42 | 69 | 24 | ±3 |
| 50 × 25 | 67 | 42 | 69 | 24 | ±3 |
| 50 × 30 | 77 | 43 | 78 | 35 | ±3 |
| 50 × 40 | 79 | 43 | 78 | 35 | ±3 |
| 50 × 50 | 87 | 43 | 78 | 33 | ±3 |
| 60 × 13 | 74 | 53 | 96 | 33 | ±5 |
| 60 × 20 | 71 | 45 | 96 | 33 | ±5 |
| 60 × 25 | 71 | 47 | 96 | 33 | ±5 |
| 60 × 30 | 81.5 | 49 | 96 | 33 | ±5 |
| 60 × 40 | 84.5 | 52 | 96 | 48 | ±5 |
| 60 × 50 | 91.5 | 50 | 96 | 48 | ±5 |
| 60 × 60 | 98 | 50 | 96 | 48 | ±5 |
| 75 × 25 | 74 | 50 | 135 | 41 | ±5 |
| 75 × 40 | 87 | 50 | 135 | 41 | ±5 |
| 75 × 50 | 95 | 50 | 135 | 60 | ±5 |
| 75 × 60 | 102 | 52 | 135 | 60 | ±5 |
| 75 × 75 | 130 | 59 | 135 | 61 | ±5 |
| 80 × 40 | 93 | 56 | 139 | 46 | ±5 |
| 80 × 50 | 101 | 56 | 139 | 66 | ±5 |
| 80 × 60 | 109 | 57 | 139 | 66 | ±5 |
| 80 × 75 | 140 | 65 | 144 | 66 | ±5 |
| 80 × 80 | 145 | 65 | 139 | 66 | ±5 |
| 100 × 40 | 104 | 69 | 157 | 60 | ±5 |
| 100 × 50 | 114 | 69 | 157 | 61 | ±5 |
| 100 × 60 | 121 | 70 | 157 | 61 | ±5 |
| 100 × 75 | 153 | 77 | 157 | 83 | ±5 |
| 100 × 80 | 158 | 77 | 157 | 83 | ±5 |
| 100 × 100 | 160 | 79 | 157 | 83 | ±5 |
